Description
UEFB210-30 bearing is a 1-7/8″ bore three-bolt normal-duty flange bracket bearing that utilizes a Tru-Loc device to secure to a 1-7/8″ shaft. UEFB210-30 flange bearings are designed with a metric-based housing, and for circumstances where the bearing is needed in a limited space application and is to be mounted on one side, the three mounting holes provide excellent stability and control for the mounted bearing. Our superior UEFB210-30 bearing with a 1-7/8″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our UEFB210-30 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. UEFB210-30 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our UEFB210-30 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UEFB210-30 bearings, and we will be happy to assist you!
UEFB210-30 Bearing Dimensions
- Part #: UEFB 210-30
- Shaft Diameter (d): 1-7/8″
- Dimension (A): 7.24″
- Dimension (H): 2.68″
- Dimension (E): 2.28″
- Dimension (J): 1.81″
- Dimension (I): 0.87″
- Dimension (G): 0.71″
- Dimension (L): 1.57″
- Dimension (S): 0.47″
- Dimension (B): 4.41″
- Dimension (F): 3.39″
- Dimension (Z): 2.19″
- Dimension (Bi): 2.0709″
- Dimension (N): 0.7480″
- Dimension (M): 1.2835″
- Bolt Used: 3/8
- Dynamic Load Rating (LBS): 7,867
- Static Load Rating (LBS): 5,330
- Bearing Insert: UE 210-30
- Housing Number: FB 210
- Weight (LBS): 5.3
