Description
SBPF207-20G stamped steel bearing is a 3-bolt flange bearing designed for light-duty industrial and agricultural applications. The superior quality greasable stamped steel housing encases a performance C3 precision 1-1/4″ insert bearing that utilizes set screws for securing onto a shaft. SBPF207-20G bearings are more economical than their cast counterparts but offer excellent performance in bearing applications; the three-bolt flange stamped steel housing allows for great mounting when the shaft is positioned perpendicular to the bearing. Utilizing three mounting holes, the SBPF207-20G 1-1/4″ bearing has incredible holding power and stability. Additionally, our SBPF207-20G stamped steel bearing features a zinc plated housing for added protection against the elements in corrosive or outdoor applications, and is equipped with a grease zerk for re-lubing capabilities. For more information or to get a quote on our SBPF207-20G bearing, contact our customer support team, and we will be happy to assist you!
SBPF207-20G Bearing Dimensions
- Part #: SBPF207-20G
- Bearing ID: 1-1/4″
- Dimension (a): 4-13/16″
- Dimension (e): 3-15/16″
- Dimension (g): 7/64″
- Dimension (c): 3/4″
- Dimension (s): 13/32″
- Dimension (f): 3-3/16″
- Dimension (Bi): 1.260″
- Dimension (n): 0.335″
- Bolt Size: 3/8″
- Number of Bolt Holes: 3
- Insert Bearing #: SB207-20
- Housing #: PF207G
- Weight: 1.45 LBS
