Description
UCWFC201-8 bearing is a 1/2″ bore four-bolt normal-duty flange bearing that utilizes set screws to secure to a 1/2″ shaft and has an metric based housing. UCWFC201-8 flange cartridge bearings are designed for circumstances where the bearing is mounted to a surface that is perpendicular to the shaft axis. Our superior UCWFC201-8 bearing with a 1/2″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our UCWFC201-8 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, relubricating capabilities, and strategically placed set screws. UCWFC201-8 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our UCWFC201-8 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UCWFC201-8 bearings, and we will be happy to assist you!
UCWFC201-8 Bearing Dimensions
- Part #: UCWFC201-8
- Shaft Diameter (d): 1/2″
- Dimension (A): 3.54″
- Dimension (P): 2.76″
- Dimension (E): 1.95″
- Dimension (I): 0.39″
- Dimension (S): 0.39″
- Dimension (J): 0.16″
- Dimension (K): 0.20″
- Dimension (G): 0.75″
- Dimension (F): 2.17″
- Dimension (Z): 1.02″
- Dimension (Bi): 1.0787″
- Dimension (N): 0.3937″
- Dimension (M): 0.6260″
- Bolt Used: 5/16
- Dynamic Load Rating (LBS): 2,147
- Static Load Rating (LBS): 1,075
- Bearing Insert: UCW 201-8
- Housing Number: WFC 203
- Weight (LBS): 1.3
