Description
UEP211-35 bearing is a two-bolt normal duty pillow block bearing with a 2-3/16″ bore. It utilizes A Tru-Loc locking device for locking onto a 2-3/16″ shaft and features a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Our UEP211-35 bearings are engineered and manufactured to provide long-lasting performance and durability with added features such as a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. UEP211-35 pillow block bearings are utilized in a wide range of applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Additionally, this UEP211-35 bearing is directly interchangeable with other brands. For further information or to get a quote on our UEP211-35 bearings contact our customer support team and we will be happy to assist you!
UEP211-35 Bearing Dimensions
- Part #: Uep 211-35
- Shaft Diameter (d): 2-3/16″
- Dimension (H): 2.500″
- Dimension (A): 8.69″
- Dimension (E): 6.75″
- Dimension (B): 2.38″
- Dimension (S2): 0.91″
- Dimension (S1): 0.71″
- Dimension (G): 0.91″
- Dimension (W): 4.94″
- Dimension (Bi): 2.2283″
- Dimension (N): 0.8740″
- Dimension (M): 1.3150″
- Bolt Used: 5/8
- Dynamic Load Rating (LBS): 9,743
- Static Load Rating (LBS): 6,608
- Bearing Insert: UE 211-35
- Housing Number: P 211
- Weight (LBS): 7.7
